Mechanical symbols include surface texture symbols, datum identifiers and targets, taper, center hole, and weld symbols, significantly saving your time and improving your design accuracy. It determines the suitable distance from the dimensioned object, making the linear dimensions look neat and clear. Overlapping dimensions can be automatically spaced apart appropriately. With Multiple Dimensions, you can create multiple dimensions with minimal input and properly space ordinate, parallel or symmetric items.
Power Dimension makes dimensioning easier with abbreviated dialog boxes that control and expand only the variables relevant to manufacturing and integrate tolerance and fit list information. Centerlines can be drawn to one single entity or multiple entities.
You can add a centerline to a circle or rectangle by selecting objects. Construction lines can be used as references to create other objects and make drafting easier. The program includes 32 options to create construction lines and seven options to create construction circles. Inventor 3D CAD software offers an easy-to-use set of tools for 3D mechanical design, documentation, and product simulation. Free download ZWCAD Mechanical 2023 SP1 full version standalone offline installer for Windows PC, ZWCAD Mechanical 2023 Overview ZWCAD license provides lifetime access to the ZWCAD software without monthly or yearly fees.
